Specifications
|
|
Model
|
CS-H1c
|
|
Camera
|
|
Image Sensor
|
1/3" Progressive Scan
CMOS
|
|
Shutter Speed
|
Self-adaptive shutter
|
|
Lens
|
2.4mm, view
angle:108°(Diagonal), 91° (Horizontal), 50°(Vertical)
|
|
Minimum Illumination
|
0.5 Lux @(F2.2, AGC ON),
0.1 Lux with IR
|
|
Lens Mount
|
M12
|
|
Day & Night
|
IR-cut filter with
auto-switching
|
|
DNR
|
3D DNR
|
|
IR Night Vision Distance
|
Up to 32 ft / 10 m
|
|
Video & Audio
|
|
Max. Resolution
|
1920 × 1080
|
|
Frame Rate
|
Max: 25 fps; Self-Adaptive
during network transmission
|
|
Video Compression
|
H.264
|
|
H.264 Type
|
Main Profile
|
|
Video Bit Rate
|
HD; Standard. Adaptive bit
rate.
|
|
Audio Bit Rate
|
Self-Adaptive
|
|
Max. Bitrate
|
1 Mbps
|
|
Function
|
|
Smart Alert
|
Motion detection
|
|
Two-way Talk
|
Supports
|
|
General Function
|
Anti-Flicker, Dual-Stream,
Heart Beat, Mirror Image, Password Protection, Watermark
|
|
Network
|
|
Standard
|
IEEE802.11b, 802.11g,
802.11n
|
|
Frequency Range
|
2.4 GHz ~ 2.4835 GHz
|
|
Channel Bandwidth
|
Supports 20 MHz
|
|
Security
|
64/128-bit WEP, WPA/WPA2,
WPA-PSK/WPA2-PSK
|
|
Transmission Rate
|
11b: 11 Mbps, 11g: 54 Mbps,
11n: 72 Mbps
|
|
Wi-Fi Pairing
|
AP pairing
|
|
Protocol
|
EZVIZ Cloud Proprietary
Protocol
|
|
Interface Protocol
|
EZVIZ Cloud Proprietary
Protocol
|
|
Storage
|
|
Local Storage
|
Supports microSD card (Up
to 512 GB)
|
|
Cloud Storage
|
Supports EZVIZ CloudPlay
storage (subscription required)
|
|
General
|
|
Operating Conditions
|
-10 ºC ~ 45 ºC (14 °F ~ 113
°F ), Humidity 95% or less (non-condensing)
|
|
Power Supply
|
DC 5V / 1A
|
|
Power Consumption
|
MAX. 3.0 W
|
|
Dimensions
|
53.89 × 53.89 × 90.3 mm
(2.12 × 2.12 × 3.56 inch)
|
|
Packaging Dimensions
|
91.5 × 87.5 × 149 mm (3.60
× 3.44 × 5.87 inch)
|
|
Net Weight
|
87 g (3.07 oz)
|
|
Weight (With Package)
|
305 g (10.76 oz)
|
|
In the box
|
|
In the box
|
H1c Camera ×1
|
|
Power Adapter x1
|
|
2-Meter Power Cable x1
|
|
Foam Sticker x2
|
|
Metal Plate x1
|
|
Regulatory Information
x2
|
|
Quick Start Guide x1
|
|
Certifications
|
|
Certifications
|
CE/RoHS/WEEE/REACH
|
