CAMARA ICSEE EXTERIOR WIFI 2MP IPG-Q20X4-WEQ
Features:
2MP Bullet and 2MP Dome cameras spliced into 4MP with clear and detailed image;
Support human shape detection, tracking and capturing;
Support dual light, human shape and intelligence (line mixing, area care, etc.);
Support for wired and wireless connections
Support 2D/3D noise reduction,digital wide dynamic;
Advanced H.265AI video compression,Super low rate,high definition quality of image;
Professional anti-lightning,conform to GB/T17626.5 and IEC61000-4-5;
Support ONVIF;access third party;
Support various mobile monitoring(iPhone,Android);
Support cloud technology,easy to achieve network penetration,fro in-line and alarm information pushed;
Model IPG-Q20X4-WEQ
System structure dual-core 32-bit DSP（XM650V200）,pure hard compression ,watch dog
Sensor 2 pcs 1080P 1/2.8" CMOS sensor
Video compression H.265AI coding,support dual stream,AVI;0.1M~10Mpbs variable
Min.Illumination Color：0.01Lux @(F1.2,AGC ON); 0 Lux with IR
Black/White: 0.001 Lux @ (F1.2,AGC ON),0 Lux with IR
Image output Main stream: 1920*2160@12fps; sub-stream:800*896@12fps
Shutter 1/50(1/60)s to 1/10,000s
Lens N/A
Day and night Support IR-CUT
Noise reduction Support 2D/3D
Wide dynamic Support
Auto iris N/A
Audio compression G.711 standard compression,support two-way Bidrectional Talk,support for audio and video synchronization
Audio interface 1ch input,level:2Vp-p,impedance:1kΩ,support sound pick-up input;1ch output,impedance:16Ω,30mw,support microphone;
Network interface 1 RJ45 Ethernet interface, 10/100M adaptive
Extension interface N/A
Singal interface one IR-CUT interface
PTZ interface One horizontal motor interface, one vertical motor interface
Alarm I/O N/A
Network interface supporting wireless network connection
Reset interface Support
Storage mode Local TF card, up to 128G; cloud storage
Reliability Comprehensive lightning protection, 7 * 24 hours 65 ℃ high temperature stable and reliable testing
Intelligence analysis Supporting human detection ,support to customizing other intelligent functions
Other function It supports remote monitoring of mobile client, push message after alarm of human figure detection, and supports MJPEG capture;
ONVIF support
Mobile monitoring support
Power DC12V
Other N/A
| Marca | HKS |
