PARADOX Glass Break Detector DG457 /
Features
Breakage in panes of glass 40.6 x 61 cm (16 x 24 in.)
or larger are detected
Effective coverage of plate, tempered, and laminated glass without the need
for complicated sensitivity adjustments
Two operational modes: EVO bus or conventional relay operation
Anti-tamper switch
Full audio and infrasonic spectrum analysis
7 frequency digital filters, digital amplifier gain, and frequency
fluctuation assessment
Impact and shock wave analysis
High-immunity to RFI and EMI signals
Specifications
Detection Range Adjustable between 1.2 to 9m (4 to 29.5 ft)
depending on environment and sensitivity settings
Input Voltage 9 to 16 Vdc
Current Consumption 35 mA
Alarm Output Available Form A (N.C.) or via bus
Sensitivity Adjustment Covers up to 9m (30 ft) when set to high, and up to
4.5m (15 ft) when set to low
Operating Temperature -20 to 50 °C (-4 to 122 °F)
Dimensions 6.6 x 9 x 2.2 cm (2.6 x 3.6 x 0.9 in.)
