PARADOX High-Security Motion Detector Module DM70
2 x dual opposed element PIR sensors
Auto-Pulse Signal Processing* (APSP)
Anti-tamper switch
4-wire bus connection
Specifications
Detection Range 11 x 11m (35 x 35 ft) at 90°
Pet Immunity Up to 40 kg (90 lb)
Input Voltage 9 to 16 Vdc
Current Consumption Typical: 16 mA, Maximum: 30 mA
Operating Temperature -20 to 50 °C (-4 to 122 °F)
Dimensions 6.5 x 12.6 x 5.5 cm (2.6 x 4.9 x 2.2 in.)
