PARADOX Wireless Expansion Module RTX3
Input Voltage 9 to 16 Vdc
Current Consumption 50 mA
RF Frequency 433 or 868 MHz
Sensitivity -120 dBm
Humidity 5 to 90%
Operating Temperature 0 to 49 °C (32 to 120 °F)
Dimensions 15 x 16 x 3 cm (6 x 6.5 x 1.1 in.)
Features
32 wireless addressable zones
Maximum number of remote controls: 999 with EVO (32 with SP)
Remote control compatibility:
• REM1, REM2, REM3, REM15, REM101, RAC1, and RAC2 remote controls
Supports wireless PGMs (8 with EVO, 16 with SP Series only)
Supports SR150 and SR130 Wireless Sirens (SP Series only)
Supports all MAGELLAN transmitters including 2WPGM
Supports 2 RPT1 and 8 K32RF / K37 (SP Series only)
RF jamming supervision
Low battery, tamper and check-in supervision for reconnected modules
Transmitter signal strength display
3 PGM outputs and 1 optional output
• PGM outputs: PGM1 and PGM2 - 150mA PGM transistor outputs
• PGM3 and PGM4 - form C relay output rated at 5A / 28Vdc, N.O. / N.C.
(PGM4 optional)
In-field firmware upgradeable via 307US
